Quickjack BL-3500SLX Portable Car Lift

1,045.00 Excl. Vat/Btw

In Stock
VAT will be exempt if a valid VAT EU number is provided



The QuickJack™ BL-3500SLX is the ultra-portable lifting system for car lovers of all kinds. Wrench with ease in your garage or shave off seconds at the track. QuickJack will make all your automotive hobbies faster and safer than ever before.


BL-3500SLX Portable Car Lift
• Capacity: 1.588KG
• Liftpointspread: Min. 678mm Max. 1238 mm
• collapsed: 75 mm
• Max height: 508 mm
Hydraulic Oil not included.

208-240V AC Power-unit 50-60Hz
• Watt: 550
• Amps: 5-8
Electric plug not included.

12-Volt DC Power-unit
• Watt: 800
• Amps: 66

Svuota

 BL-3500SLX Portable Car Lifting System

Less labor and more love. The QuickJack BL-3500SLX light-weight portable car lifting system will change everything about how you maintain your vehicles. Say goodbye to ramps and flimsy jacks–with the QuickJack BL-3500SLX, you can get your vehicle in the air in literally seconds. The BL-3500SLX has a maximum lifting capacity of 3,500-lb. But its true strength is that you can take it with you. The QuickJack is so light-weight and space-efficient that you can transport it in your regular sized trunk or backseat. It also takes seconds to get up and running following initial one-time assembly. Just drop it on the ground and hook-up the power. As soon as the jack frames and rubber blocks are in place under your vehicle, it’ll be at a work-ready height in no time at all. It’s really that easy. At a super-low profile of three inches, the QuickJack garage lift fits where other jacks only dream. And because there aren’t any cross members to worry about with this portable garage lift, you can tailor the platform spacing perfectly to nearly any vehicle. Check out the our other products!

Long list of design features…

  • 3500-pound capacity
  • Extended lifting point spread
  • From stow to go in less than 60-seconds
  • Dual-position automatic safety lock bars engage automatically as the lift rises
  • Dual locking positions – mid level and full rise
  • Extended, cantilevered rubber block trays provide increased rubber block reach
  • Portable power unit features a remote push-button control for simple operation
  • Steel mounted urethane wheels provide effortless rolling of jack frames on floor
  • Remote pendant control features a 13-foot cord
  • Power unit features a built-in hydraulic flow divider for precise equalized lifting
  • Open-center design for clear under car access
  • Quick-connect/disconnect hoses for fast and convenient set-up
  • Convenient handles allow for easy positioning of the jack frames
  • Strong 14-gauge welded steel frames
  • It’s a jack you can use when you need it then conveniently store out of the way
  • Provides quick wheels-free convenience for brake and tire service and clear undercarriage access of all types of vehicles
  • Low-profile jack frames fit under most race cars
  • Powerful hydraulic cylinders eliminate the need for screw mechanisms
  • Integrated power-assist canisters increase the lowering speed
  • Hydraulic cylinders feature integrated velocity-fuse safety valves
  • A convenient metal carrier with handle keeps the power unit protected and easily mobile
  • Includes an eight piece set of adjustable and stackable rubber lift blocks to support cars at precise locations for increased stability and safety
  • Detailed installation, maintenance and safety instructions accompany each QuickJack system
  • Durable powder coat finish
Specifications BL-3500SLX

MODEL

BL-3500SLX

LIFTING CAPACITY 1588 kg.
(A) COLLAPSED 76 mm
(B) COLLAPSED W/ SMALL BLOCK 89 mm
(C) RAISED (FRAME ONLY) 419 mm
(D) RAISED (SMALL BLOCK) 432 mm
(E) RAISED (LARGE BLOCK) 470mm
(F) RAISED (STACKED BLOCKS) 508 mm
(G) SUV ADAPTERS Not Compatible
(H) SUV ADAPTERS (W/ PIN) Not Compatible
(I) LIFTING POINT SPREAD – MAX 1283 mm
(J) LIFTING POINT SPREAD – MIN 678 mm
(K) FRAME WIDTH 268mm
(L) FRAME LENGTH 1575mm
FRAME WEIGHT 27 kg
POWER UNIT WEIGHT 35 lbs. / 16 kg
SHIPPING WEIGHT 82 kg
Noise < 45dBA

POWER UNIT ELECTRICAL SPECIFICATIONS

MOTOR

HERTZ

KW

PHASE

AMPS

12-Volt DC N/A 0.8 N/A 70
110-Volt AC 60 0.55 1 10-15
208-230-Volt AC 50/60 0.55 1 5-8
240 Volt AC 50 0.55 1 4-6
  IMPORTANT NOTE: EXTENSION CORDS ARE NOT RECOMMENDED. Using extensions cords can adversely affect operation and can cause overheating conditions and damage to power unit. If using an extension cord, use the shortest cord possible. Refer to extension cord size chart below.

Cord Length

AWG size/rating

25 feet 14 gauge
50 feet 14 gauge
75 feet 12 gauge

Informazioni aggiuntive

Specificaties

Weight capacity: 3,500-lbs. / 1588 kg.
Individual frame weight: 45 lbs. / 27 kg.
Platform lifting height (frame only): 16.75” / 406 mm.
Platform lifting height (with rubber lift blocks): 20” / 508 mm.
Minimum collapsed height: 3” / 76 mm.
Rubber block position MIN: 28.75” / 678mm.
Rubber block position MAX: 43.75” / 1283 mm.
Frame width: 10.5” / 267 mm.
Frame length: 61.5” / 1562 mm.
Lifting time: 25 seconds
Packaged weight (jack system complete – less power unit): 108 lbs. / 66 kg.
Packaged weight (power unit and power unit carrier): 18 lbs. / 16 kg.

Power-unit Opties

12-Volt DC Power-Unit, 208-240 Volt AC Power-unit

~

Installation / Operation / Maintenance Manual PDF

QuickJack Garage Lift Parts Diagram

Vehicle Measurement Worksheet

QuickJack Cylinder Designator

Important Tech Bulletin - Never Raise QuickJack With No Vehicle Load

QuickJack Portable Car Lift Manual (All Models) (pdf) UPDATED - DEC 2017
